Hey, Remember vTax?

Hey, remember vTax/vRAM? It’s dead and gone, but with 6 Terabyte of RAM servers now available, imagine what could have been (your insanely high licensing costs).

Set the wayback machine to 2011, when VMware introduced vSphere version 5. It had some really great enhancements over version 4, but no one was talking about the new features. Instead, they talked about the new licensing scheme and how much it sucked.


While some defended VMware’s position, most were critical, and my own opinion… let’s just say I’ve likely ensured I’ll never be employed by VMware. Fortunately, VMware came to their senses and realized what a bone-headed, dumbass move that vRAM/vTax was, and repealed the vRAM licensing one year later in 2012. So while I don’t want to beat a dead horse (which, seriously, disturbing idiom), I do think it’s worth looking back for just a moment to see how monumentally stupid that licensing scheme was for customers, and serve as a lesson in the economies of scaling for the x86 platform, and as a reminder about the ramifications of CapEx versus OpEx-oriented licensing.

Why am I thinking about this almost 2 years after they got rid of vRAM/vTax? I’ve been reading up on the newly released Intel’s E7 v2 processors, and among the updates to Intel’s high-end server chip is the ability to have 24 DIMMs per socket (the previous limit was 12) and the support of 64 GB DIMMs. This means that a 4-way motherboard (which you can order now from Cisco, HP, and others) can support up to 6 TB of RAM, using 96 DIMM slots and 64 GB DIMMs. And you’d get up to 60 cores/120 threads with that much RAM, too.

And I remembered one (of many) aspects about vRAM that I found horrible, which was just how quickly costs could spiral out of control, because server vendors (which weren’t happy about vRAM either) are cramming more and more RAM into these servers.

The original vRAM licensing with vSphere 5 was that for every socket you paid for, you were entitled to/limited to 48 GB of vRAM with Enterprise Plus. To be fair the licensing scheme didn’t care how much physical RAM (pRAM) you had, only how much of the RAM was consumed by spun-up VMs (vRAM). With vSphere 4 (and the current vSphere licensing, thankfully), RAM had been essentially free: you only paid per socket. You could use as much RAM as you could cram into a server.  But with the vRAM licensing, if you had a dual-socket motherboard with 256 GB of RAM you would have to buy 6 licenses instead of 2. At the time, 256 GB servers weren’t super common, but you could order them from the various server vendors (IBM, Cisco, HP, etc.). So with vSphere 4, you would have paid about $7,000 to license that system. With vSphere 5, assuming you used all the RAM, you’d pay about $21,000 to license the system, a 300% increase in licensing costs. And that was day 1.

Now lets see how much it would cost to license a system with 6 TB of RAM. If you use the original vRAM allotment amounts from 2011, each socket granted you 48 GB of vRAM with Enterprise Plus (they did up the allotments after all of the backlash, but that ammended vRAM licensing model was so convoluted you literally needed an application to tell you how much you owed). That means to use all 6 TB (and after all, why would you buy that much RAM and not use it), you would need 128 socket licences, which would have cost $448,000 in licensing. A cluster of 4 vSphere hosts would cost just shy of $2 million to license. With current, non-insane licensing, the same 4-way 6 TB server costs a whopping $14,000. That’s a 32,000% price differential.

Again, this is all old news. VMware got rid of the awful licensing, so it’s a non-issue now. But still important to remember what almost happened, and how insane licensing costs could have been just a few years later.


My graph from 2011 was pretty accurate.

Rumor has it VMware is having trouble getting customers to go for OpEx-oriented licensing for NSX. While VMware hasn’t publicly discussed licensing, it’s a poorly kept secret that VMware is looking to charge for NSX on a per VM, per month basis. The number I’d been hearing is $10 per month ($120 per year), per VM. I’ve also heard as high as $40, and as low as $5. But whatever the numbers are, VMware is gunning for OpEx-oriented licensing, and no one seems to be biting. And it’s not the technology, everyone agrees that it’s pretty nifty, but the licensing terms are a concern. NSX is viewed as network infrastructure, and in that world we’re used to CapEx-oriented licensing. Some of VMware’s products are OpEx-oriented, but their attempt to switch vSphere over to OpEx was disastrous. And it seems to be the same for NSX.

Changing Data Center Workloads

Networking-wise, I’ve spent my career in the data center. I’m pursuing the CCIE Data Center. I study virtualization, storage, and DC networking. Right now, the landscape in the network is constantly changing, as it has been for the past 15 years. However, with SDN, merchant silicon, overlay networks, and more, the rate of change in a data center network seems to be accelerating.


Things are changing fast in data center networking. You get the picture

Whenever you have a high rate of change, you’ll end up with a lot of questions such as:

  • Where does this leave the current equipment I’ve got now?
  • Would SDN solve any of the issues I’m having?
  • What the hell is SDN, anyway?
  • I’m buying vendor X, should I look into vendor Y?
  • What features should I be looking for in a data center networking device?

I’m not actually going to answer any of these questions in this article. I am, however, going to profile some of the common workloads that you find in data centers currently. Your data center may have one, a few, or all of these workloads. It may not have any of them. Your data center may have one of the workloads listed, but my description and/or requirements is way off. All certainly possible. These are generalizations, and with all generalizations your mileage may vary. With that disclaimer out of the way, strap in. Let’s go for a ride.

Traditional Virtualization

It’s interesting to say that something which only exploded into the data center in a big way in about 2008 as now being “traditional”, rather than “new-fangled”. But that’s the situation we have here. Traditional virtualization workload  is centered primarily around VMware vSphere. There are other traditional virtualization products of course, such as Red Hat’s RHEV, Xen, and Microsoft Hyper-V, but VMware has the largest market share for this by far.

  • Latency is not a huge concern (30 usecs not a big deal)
  • Layer 2 adjacencies are mandatory (required for vMotion)
  • Large Layer 2 domains (thousands of hosts layer 2 adjacent)
  • Converged infrastructures (storage and data running on the same wires, FCoE, iSCSI, NFS, SMB3, etc.)
  • Buffer requirements aren’t typically super high. Bursting isn’t much of an issue for most workloads of this type.
  • Fibre Channel is often the storage protocol of choice, along with NFS and some iSCSI as well

Cisco has been especially successful in this realm with the Nexus line because of vPC, FabricPath, OTV and (to a much lesser extent) LISP, as they address some of the challenges with workload mobility (though not all of them, such as the speed of light). Arista, Juniper, and many others also compete in this particular realm, but Cisco is the market leader.

With the multi-pathing Layer 2 technologies such as SPB, TRILL, Cisco FabricPath, and Brocade VCS (the latter two are based on TRILL), you can build multi-spine leaf/spine networks/CLOS networks that you can’t with spanning-tree based networks, even with MLAG.

This type of network is what I typically see in data centers today. However, there is a shift towards Layer 3 networks and cloud workloads over traditional virtualization, so it will be interested to see how long traditional virtualization lasts.


VDI (Virtual Desktops) are a workload with the exact same requirements as traditional virtualization, with one main difference: The storage requirements are much, much higher.

  • Latency is not as important (most DC-grade switches would qualify), especially since latency is measured in milliseconds for remote desktop users
  • Layer 2 adjacencies are mandatory (required for vMotion)
  • Large Layer 2 domains
  • Converged infrastructures
  • Buffer requirements aren’t typically very high
  • High-end storage backends. All about the IOPs, y’all

For storage here, IOPs are the biggest concern. VDI eats IOPs like candy.

Legacy Workloads

This is the old, old school. And by old school, I mean late 90s, early 2000s. Before virtualization changed the landscape. There’s still quite a few crusty old servers, with uptimes measured in years, running long-abandoned applications. The problem is, these types of applications are usually running something mission critical and/or significant revenue generating. Organizations just haven’t found a way out of it yet. And hey, they’re working right now. Often running on proprietary Unix systems, they couldn’t or wouldn’t be migrated to a virtualized environment (where it would be much easier to deal with).

The hardware still works, so why change something that works? Because it would be tough to find more. It’s also probably out of vendor-supported service.

  • Latency? Who cares. Is it less than 1 second? Good enough.
  • Layer 2 adjacencies, if even required, are typically very small, typically just needed for the local clustering application (which is usually just stink-out-loud awful)
  • 100 megabit and gigabit Ethernet typically. 10 Gigabit? That’s science-fiction talk!
  • Buffers? You mean like, what shines the floor?


My own personal opinion is that this is the only place where Cisco Catalyst switches belong in a data center, and even then only because they’re already there. If you’re going with Cisco, I think everything else (and everything new) in the DC should be Nexus.

Cloud Workloads (Private Cloud)

If you look at a cloud workload, it looks very similar to the previous traditional virtualization workload. They both use VMs sitting on top of hypervisors. They both have underlying infrastructure of compute, network, and storage to support these VMs. The difference is primarily is in the operational model.

It’s often described as the difference between pets and cattle. With traditional virtualization, you have pets. You care what happens to these VMs. They have HA and DRS and other technologies to care for them. They’re given clever names, like Bart and Lisa, or Happy and Sleepy. With cloud VMs, they’re not given fun names. We don’t do vMotion/Live Migration with them. When we need them, they’re spun up. When they’re not, they’re destroyed. We don’t back them up, we don’t care if the host they reside on dies so long as there are other hosts carrying the workload. The workload is automatically sharded across the available hosts using logic in the application. Instead of backups, templates are used to create new VMs when the workload increases. And when the workload decreases, some of the VMs get destroyed. State is not kept on any single VM, instead the state of the application (and underlying database) is sharded to the available systems.

This is very different than traditional virtualization. Because the workload distribution is handled with the application, we don’t need to do vMotion and thus have Layer 2 adjacencies. This makes it much more flexible for the network architects to put together network to support this type of workload. Storage with this type of workload also tends to be IP-based (NFS, iSCSI) rather than FC-based (native Fibre Channel or FCoE).

With cloud-based workloads, there’s also a huge self-service component. VMs are spun-up and managed by developers or end-users, rather than the IT staff. There’s typically some type of portal that end-users can use to spin up/down resources. Chargebacks are also a component, so that even in a private cloud setting, there’s a resource cost associated and can be tracked.

OpenStack is a popular choice for these cloud workloads, as is Amazon and Windows Azure. The former is a private cloud, with the later two being public cloud.

  • Latency requirements are mostly the same as traditional virtualization
  • Because vMotion isn’t required, it’s all Layer 3, all the time
  • Storage is mostly IP-based, running on the same network infrastructure (not as much Fibre Channel)
  • Buffer requirements are typically the same as traditional virtualization
  • VXLAN/NVGRE burned into the chips for SDN/Overlays

You can use much cheaper switches for this type of network, since the advanced Layer 2 features (OTV, FabricPath, SPB/TRILL, VCS) aren’t needed. You can build a very simple Layer 3 mesh using inexpensive and lower power 10/40/100 Gbit ports.

However, features such as VXLAN/NVGRE encap/decap is increasingly important. The new Trident2 chips from Broadcom support this now, and several vendors, including Cisco, Juniper, and Arista all have switches based on this new SoC (switch-on-chip) from Broadcom.

High Frequency Trading

This is a very specialized market, and one that has very specialized requirements.

  • Latency is of the utmost concern. To the point of making sure ports are on the same ASIC. Latency is measured in nano-seconds, microseconds are an eternity
  • 10 Gbit at the very least
  • Money is typically not a concern
  • Over-subscription is non-existent (again, money no concern)
  • Buffers are a trade off, they can increase latency but also prevent packet loss

This is a very niche market, one that Arista dominates. Cisco and a few other vendors have small inroads here, using the same merchant silicon that Arista uses, however Arista has had huge experience in this market. Every tick of the clock can mean hundreds of thousands of dollars in a single trade, so companies have no problem throwing huge amounts of money at this issue to shave every last nanosecond off of latency.

Hadoop/Big Data

  • Latency is of high concern
  • Large buffers are critical
  • Over-subscription is low
  • Layer 2 adjacency is neither required nor desired
  • Layer 3 Leaf/spine networks
  • Storage is distributed, sharded over IP

Arista has also extremely successful in this market. They glue PC RAM onto their switch boards to provide huge buffers (around 760 MB) to each port, so it can absorb quite a bit of bursty traffic, which occurs a lot in these types of setups. That’s about .6 seconds of buffering a 10 Gbit link. Huge buffers will not prevent congestion, but they do help absorb situations where you might be overwhelmed for a short period of time.

Since nodes don’t need to be Layer 2 adjacent, simple Layer 3 ECMP networks can be created using inexpensive and basic switches. You don’t need features like FabricPath, TRILL, SPB, OTV. Just fast, inexpensive, low power ports. 10 Gigabit is the bare minimum for these networks, with 40 and 100 Gbit used for connectivity to the spines. Arista (especially with their 7500E platform) does very well in this area. Cisco is moving into this area with the Nexus 9000 line, which was announced late last year.



Understanding the requirements for the various workloads may help you determine the right switches for you. It’s interesting to see how quickly the market is changing. Perhaps 2 years ago, the large-Layer 2 networks seemed like the immediate future. Then all of a sudden Layer 3 mesh networks became popular again. Then you’ve got SDN like VMware’s NSX and Cisco’s ACI on top of that. Interesting times, man. Interesting times.

FCoE versus FC Farce (I’m Tellin’ All Y’All It’s Sabotage!)

Updates 2/6/2014:

  • @JohnKohler noticed that the UCS Manager screenshot used (see below) is from a UCS Emulator, not any system they used for testing.
  • Evaluator Group promises answers to questions that both I and Dave Alexander (@ucs_dave) have brought up.

On my way back from South America/Antarctica, I was pointed to a bake-off/performance test commissioned by Brocade and performed by a company called Evaluator Group. It compared the performance of edge FCoE (non-multi-hop FCoE) to native 16 Gbit FC. The FCoE test was done on a Cisco UCS blade system connecting to a Brocade switch, and the FC was done on an HP C7000 chassis system connecting to the same switch. At first glance, it would seem to show that FC is superior to FCoE for a number of reasons.

I’m not a Cisco fanboy, but I am a Cisco UCS fanboy, so I took great interest in the report. (I also work for a Cisco Learning Partner as an instructor and courseware developer.) But I also like Brocade, and have a huge amount of respect for many of Brocade employees that I have met over the years. These are great and smart people, and they serve their customers well.

First, a little bit about these types of reports. They’re pretty standard in the industry, and they’re commissioned by one company to showcase superiority of a product or solution against one or more of their competitors. They can produce some interesting information, but most of the time it’s a case of: “Here’s our product in a best-case scenario versus other products in a mediocre-to-worst case scenario.” No company would release a test showing other products superior to theirs of course, so they’re only released when a particular company comes out on top, or (most likely) the parameters are changed until they do. As such, they’re typically taken with a grain of salt. In certain markets, such as the load balancer market, vendors will make it rain with these reports on a regular basis.

But for this particular report, I found several substantial issues with it which I’d like to share. It’s kind of a trainwreck. Let’s start with the biggest issue, one that is rather embarrassing.

What The Frak?

On page 17 check out the Evaluator Group comments:

“…This indicates the primary factor for higher CPU utilization within the FCoE test was due to using a software initiator, rather than a dedicated HBA. In general, software initiators require more server CPU cycles than do hardware initiators, often negating any cost advantages.”

For one, no shit. Hardware initiators will perform better than software initiators. However, the Cisco VIC 1240 card (which according to page 21 was included in the UCS blades) is a hardware initiator card. Being a CNA (converged network adaptor) the OS would see a native FC interface. With ESXi you don’t even need to install extra drivers, the FC interfaces just show up. Setting up a software FCoE initiator would actually be quite a bit more difficult to get going, which might account for why it took so long to configure UCS. Configuring a hardware vHBA in UCS is quite easy (it can be done in literally less than a minute).

Using software initiators against hardware FC interfaces is beyond a nit-pick in a performance test. It would be downright sabotage.


I asked the @Evalutor_Group account if they really did software initiators:

And they responded in the affirmative.

Wow. First of all, software FCoE initiators is absolutely not standard configuration for UCS. In the three years I’ve been configuring and teaching UCS, I’ve never seen or even heard of FCoE software initiators being used, either in production or in a testing environment. The only reason you *might* want to do FCoE software initiators is when you’ve got the Intel mezzanine card (which is not a CNA, just an Ethernet card), and want to test FCoE. However, on page 21 it shows the UCS blades has having the VIC 1240 cards, not the Intel card.

So where were they getting that it was standard configuration?

They countered with a reference to a UCS document regarding the VIC:

and then here:

Which is this document here.

The part they referenced is as follows:

The adapter offerings are:

■ Cisco Virtual Interface Cards (VICs)

Cisco developed Virtual Interface Cards (VICs) to provide flexibility to create multiple NIC and HBA devices. The VICs also support adapter Fabric Extender and Virtual Machine Fabric Extender technologies.

■ Converged Network Adapters (CNAs)

Emulex and QLogic Converged Network Adapters (CNAs) consolidate Ethernet and Storage (FC) traffic on the Unified Fabric by supporting FCoE.

■ Cisco UCS Storage Accelerator Adapters

Cisco UCS Storage Accelerator adapters are designed specifically for the Cisco UCS B-series M3 blade servers and integrate seamlessly to allow improvement in performance and relief of I/O bottlenecks.

Wait… I think they think that the VIC card is a software-only FCoE card. It appears they came to that conclusion because the VIC doesn’t specifically mention it’s a CNA in this particular document (other UCS documents clearly and correctly indicate that the VIC card is a CNA). Because it mentions the VICs separately from the traditional CNAs from Emulex and Qlogic, it seems they believe it not to be a CNA, and thus a software card.

So it may be they did use hardware initiators, and mistakenly called them software initiators. Or they actually did configure software initiators, and did a very unfair test.

No matter how you slice it, it’s troubling. On one hand, if they did configure software initiators, they either ignorantly or willfully sabotaged the FCoE results. If they just didn’t understand the basic VIC concept, it means they setup a test without understand the most basic aspects of the Cisco UCS system. We’re talking 101 level stuff, too.  I suspect it’s the later, but since the only configuration of any of the devices they shared was a worthless screenshot of UCS manager, I can’t be sure.

This lack of understanding could have a significant impact on the results. For instance, on page 14 the response time starts to get worse for FCoE at about the 1200 MB/s mark. That’s roughly the max for a single 10 Gbit Ethernet FCoE link (1250 MB/s). While not definitive, it could mean that the traffic was going over only one of the links from the chassis to the Fabric Interconnect, or the traffic distribution was way off. My guess is they didn’t check the link utilization, or even know how, or how to fix it if it were off.

Conclusions First?

One of the more odd aspects of this report are where you found some of the conclusions, such as this one:

“Evaluator Group believes that Fibre Channel connectivity is required in order to achieve the full benefits that solid-state storage is able to provide.”

That was page 1. The first page of the report is a little weird to make a conclusion like that. Makes you sound a little… biased. These reports usually try to be impartial (despite being commissioned by a particular vendor). This one starts right out with an opinion.

Lack of Configuration

The amount of configuration they provide for the setup very sparse. For the UCS side, all they provide is one pretty worthless screenshot. Same for the HP system. For the UCS part, it would be important to know how they configured the vHBAs, and how they configured the two 10 Gbit links from the IOM to the chassis. Where they configured for the preferred Fabric Port Channel, or static pinning? So there’s no way to duplicate this test. That’s not very transparent.

Speaking of configuration, one of the issues they had with the FCoE side was how long it took them to stand up a UCS system. On page 11, second paragraph, they mention they need the help of a VAR to get everything configured. They even made a comment on page 10:

“…this approach was less intuitive during installation than other enterprise systems Evalutor Group has tested.”


So wow, you’ve got an environment that you’re unfamiliar with (we’ll see just how unfamiliar in a minute), and it took you *gasp* longer to configure? I’m a bit of an expert on Cisco UCS. I’m kind of a big deal. I have many paper-bound UCS books and my apartment smells of rich mahogany. I teach it regularly. And I’m not nearly as familiar with the C7000 system from HP, so I’d be willing to bet that it would take me longer to stand up an HP system than it would a Cisco UCS system. Anyone want in on that action?

Older Version? Update 2-6-2014: Screenshot Is A Fake


@JohnKohler noticed that on the screenshot on page 23 that the serial number in the screenshot is “1”, which means the screenshot is not from any physical instance of a UCS Manager, but the UCS Emulator. The date (if accurate on the host machine) shows June of 2010, so it’s a very, very old screenshot (probably of 1.3 or 1.4). So we have no idea what version of UCS they used for these tests (and more importantly, how they were configured).

Based on the screenshot on page 23, the UCS version is 2.0. How can you tell? Take a look where it says “Unconfigured Ports”. As of 2.1, Cisco changed the way ports are shown in the GUI. 2.1 and later do not have a sub-menu for unconfigured ports. Only 2.0 and prior.


In version 2.1, there’s no “Unconfigured Ports” sub-menu.


From Page 21, you can see “Unconfigured Ports”, indicating it’s UCS 2.0 or earlier.

If the test was done in November 2013, that would put it one major revision behind, as 2.1 was released in November of 2012 (2.2 was released in Dec 2013). We don’t know where they got the equipment, but if it acquired anytime in the past year, it likely came with 2.1 already installed (but not definite). To get to 2.0, they’d have to downgrade. I’m not sure why they would have done that, and if they brought in a VAR with certified UCS people they would have likely recommended 2.1. With 2.1, they could have directly connected the storage array to the UCS fabric interconnects. UCS 2.1 can do Fibre Channel zoning, and can function as a standard Fibre Channel switch. The Brocade switch wouldn’t have been needed, and the links to the storage array would be 8 Gbit instead of 16 Gbit.

They also don’t mention the solid state array vendor, so we don’t know if there was capability to do FCoE directly to the storage array. Though not terribly common yet, FCoE connection to a storage array is done in production environments and would have benefited the UCS configuration if it were possible (and would be the preferred way if competing with 16 Gbit FC). There would have been the ability to do an LACP port channel between the Fabric Interconnects, providing better load distribution and redundancy.

Power Mad

The claim that the UCS system uses more power is laughable, especially since they specifically mentioned this setup is not how it would be deployed in production. Nothing about this setup was production worthy, and it wasn’t supposed to be. It’s fine for this type of test, but not for production. It’s non-HA, and using only 2 blades would be a waste of a blade system (and power, for either HP or Cisco). If you were only using a handful of servers, buying pizza boxes would be far more economical. Blades from either HP or Cisco only make sense past a certain number to justify the enclosures, networking, etc. If you want a good comparison, do 16 blades, or 40 blades, or 80 blades. Also include the Ethernet network connectivity. The UCS configuration has full Ethernet connectivity, the HP configuration as shown has squat.

Even by competitive report standards, this one is utter bunk. If I was Brocade, I would pull the report. With all the technology mistakes and ill-found conclusions, it’s embarrassing for them. It’s quite easy for Cisco to rip it to shreds.

(Just so there’s no confusion, no one paid me or asked me to write this. In fact, I’m still on PTO. I wrote this because someone is wrong on the Internet…)

2013 Was A Good Year

Happy new year everyone. I think 2014 will be quite an interesting year for the industry. 2013 certainly was for me, at least professionally and personally. I tried twice to get my CCIE DC, didn’t pass. I did, however, obtain my CCNP Data Center. I also learn a whole bunch of new skills. Here’s a quick clip show (and yes, there are shots of me skydiving in a Star Trek TNG Uniform).

OpenFlow/SDN Won’t Scale?

I got in a conversation today on Twitter, talking about SDN/SDF (software defined forwarding), which is a new term I totally made up which I use to describe the programmatic and centralized control of forwarding tables on switches and multi-layer switches. The comment was made that OpenFlow in particular won’t scale, which reminded me of an article by Doug Gourlay of Arista talking about scalability issues with OpenFlow.

The argument that Doug Gourlay of Arista had is essentially that OpenFlow can’t keep up with the number of new flows in a network (check out points 2 and 3). In a given data center, there would be tens of thousands (or millions or tens of millions) of individual flows running through a network at any given moment. And by flows, I mean keeping track of stateful TCP connection or UDP pseudo-flows. The connection rate would also be pretty high if you’re talking dozens or hundreds of VMs, all taking in new connections.

My answer is that yeah, if you’re going to try to put the state of every TCP connection and UDP flow into the network operating system and into the forwarding tables of the devices, that’s not going to scale. I totally agree.

But why would you do that?

Why wouldn’t you, instead of keeping track of every flow, do destination-based forwarding table entries, which is how forwarding tables on switches are currently programmed? The network operating system/controller would learn (or be told about) the specific VMs and other devices within the data center. It could learn this through conversational learning, flooding, static entries (configured by hand), automated static entries (where an API programs it in such as connectivity through vCenter), or externally through traditional MAC flooding and routing protocols.

In that case, the rate of change in the forwarding tables would be relatively low, and not much different then how switches are currently programmed with Layer 3 routes and Layer 2 adjacencies with traditional methods. This would actually be more likely shrink the size of the forwarding tables when compared with traditional Ethernet/IP forwarding, as the controller could intelligently prune the forwarding tables of the switches rather than flood and learn every MAC address on every switch that has a given VLAN configured (similar to what TRILL/FabricPath/VCS does).

We don’t track every TCP/UDP flow in a data center with our traditional networking, and I can’t think of any value-add to keeping track of every flow in a given network, even if you could. So why would OpenFlow or any other type of SDF do any different? We have roughly the same size tables, and we have the added benefit of including Layer 4, VXLAN, NVGRE, or even VLANs in the forwarding decisions.

I honestly don’t know if keeping track of every flow was the original concept with OpenFlow (I can’t imagine it would be, but there’s a lot of gaps in my OpenFlow knowledge), but it seems an API that programs a forwarding table could be made to do so without keeping traffic of every gosh darn flow.

Software Defined Fowarding: What’s In A Name?

I’ve got about four or five articles on SDN/ACI and networking in my drafts folder, and there’s something that’s been bothering me. There’s a concept, and it doesn’t have a name (at least one that I’m aware of, though it’s possible there is). In networking, we’re constantly flooded with a barrage of new names. Sometimes we even give things a name that already have a name. But naming things is important. It’s like a programming pointer, a name of something will be a pointer to a specific part of our brain that contains the understanding a of a given concept.

Software Defined Forwarding

I decided SDF needed a name because I was having trouble describing a concept, a very important one, in reference to SDN. And here’s the concept, with three key aspects:

  1. Forwarding traffic in a way that is different than traditional MAC learning/IP forwarding.
  2. Forwarding traffic based on more than the usual Layer 2 and Layer 3 headers (such as VXLAN headers, TCP and/or UDP headers).
  3. Programming these forwarding rules via a centralized controller (which would be necessary if you’re going to throw out all the traditional forwarding rules and configure this in any reasonable amount of time).
  4. In the cases of Layer 2 adjancencies, multipathing is inherent (either through overlays or something like TRILL).

Throwing out traditional rules of forwarding is what OpenFlow does, and OpenFlow got a lot of the SDN ball rolling. However, SDN has gone far beyond just OpenFlow, so it’s not fair to call it just OpenFlow anymore. And SDN is now far too broad of a term to be specific to fowarding rules, as SDN encompasses a wide range of topics, from forwarding to automation/orchestration, APIs, network function virtualization (NFV), stack integration (compute, storage), etc. If you take a look at the shipping SDN product listing, many of the products don’t have anything to do with actually forwarding traffic. Also something like FabricPath, TRILL, VCS, and SPB all do Ethernet forwarding in a non-standard way, but this is different. So herein lies the need I think to define a new term.

And make no mistake, SDF (or whatever we end up calling it) is going to be an important factor in what pushes SDN from hype to implementation.

Forwarding is simply how we get a packet from here to there. In traditional networking, forwarding rules are separate by layer. Layer 2 Ethernet forwarding works in one particular way (and not a particularly intelligent way), IP routing works in another way.  Layer 4 (TCP/UDP) gets a little tricky, as switches and routers typically don’t forward traffic based on Layer 4 headers. You can do something like policy based routing, but it’s a bit combersome to setup. You also have load balancers handling some Layer 4-7 features, but that’s handled in a separate manner.

So traditional forwarding for Layer 2 and Layer 3 hasn’t changed much. For instance, take the example of a server plugging into a switch and powering up. Its IP address and MAC address haven’t been seen on the network, so the network is unaware of both the Layer 2 and Layer 3 addresses. The server is plugged it into a switch with a port set for the right VLAN. The server wants to send a packet out to the internet, so it ARPs (WHO HAS, for example). The router (or more likely, SVI) responds with its MAC address, or the floating MAC (VMAC) of the first-hop redundancy protocol, such as VRRP or HSRP. Every switch attached to that VLAN sees this ARP and ARP response, and every switches Layer 2 forwarding table learned which port to find that particular MAC address on.


In several of the SDF implementations that I’m familiar with, such as Cisco’s ACI, NEC’s OpenFlow controller, and to a certain degree Juniper’s QFabric, things get a little weird.


Forwarding in SDF/SDN, Gets A Little Weird

In the SDF (or many implementations of SDF, they differ in how they accomplish this) the local TOR/leaf switch is what answers the server’s ARP. Another server, on the same subnet and L2 segment (or increasingly a tenant), ARPs on a different leaf switch.


In the diagram above, note both servers have a default gateway of The two servers are Layer 2 adjacent, existing on the same network segment (same VLAN or VXLAN). Both ARP for their default gateways, and both receive a response from their local leaf switch with an identical MAC address. Neither server would actually see the other’s ARP, because there’s no need to flood that ARP traffic (or most other BUM traffic) beyond the port that the server is connected to. BUM traffic goes to the local leaf, and the leaf can learn and forward in a more intelligent manner. The other leaf nodes don’t need to see the flooded traffic, and a centralized controller can program the forwarding tables of the leafs and spines accordingly.

In most cases, the packet’s forwarding decision, based on a combination of Layer 2, 3, 4 and possibly more (such as VXLAN) is made at the leaf. If it’s moving past a Layer 3 segment, the TTL gets decremented. The forwarding is typically determined at the leaf, and some sort of label or header applies that contains its destination port.

You have this somewhat with a full Layer 3 leaf/spine mesh, in that the local leaf is who answers the ARP. However, in a Layer 3 mesh hosts connected to different leaf switches are on different network segments, and the leaf is the default gateway (without getting werid).  In some applications, such as Hadoop, that’s fine. But for virtualization (unfortunately) there’s a huge need for Layer 2 adjacencies. For now, at least

Another benefit of SDF is the ability to intelligently steer traffic through various network devices, known as service chaining. This is done without changing default gateways of the servers, bridging VLANs and proxy arp, or other current methodologies. Since SDF throws out the rulebook in terms of forwarding, it becomes a much simpler matter to perform traffic steering. Cisco’s ACI does this, as does Cisco vPath and VMware’s NSX.


A policy, programmed on a central controller, can be put in place to ensure that traffic forwards through a load balancer and firewall. This also has a lot of potential in the realm of multi-tenancy and network function virtualization. In short, combined with other aspects of SDN, it can change the game in terms of how network are architected in the near future.

SDF is only a part of SDN. By itself, it’s compelling, but as there have been some solutions on the market for a little while, it doesn’t seem to be “must have” to the point where customers are upending their data center infrastructures to replace everything. I think for it to be a must have, it needs to be a part

Death To vMotion

There are very few technologies in that data center that have had as significant of an impact of VMware’s vMotion. It allowed us to de-couple operating system and server operations. We could maintain, update, and upgrade the underlying compute layer without disturbing the VMs they ran on. We can write web applications in the same model that we’re used to, when we wrote them to specific physical servers. From an application developer perspective, nothing needed to be changed. From a system administrator perspective, it helped make (virtual) server administration easier and more flexible. vMotion helped us move almost seamlessly from the physical world to the virtualization world with nary a hiccup. Combined with HA and DRS, it’s made VMware billions of dollars.

And it’s time for it to go.

From a networking perspective, vMotion has reeked havoc on our data center designs. Starting in the mid 2000s, we all of a sudden needed to build huge Layer 2 networking domains, instead of beautiful and simple Layer 3 fabrics. East-West traffic went insane. With multi-layer switches (Ethernet switches that could route as fast as they could switch), we had just gotten to the point where we could build really fast Layer 3 fabrics, and get rid of spanning-tree. vMotion required us to undo all that, and go back to Layer 2 everywhere.

But that’s not why it needs to go.

Redundant data centers and/or geographic diversification is another area that vMotion is being applied to. Having the ability to shift a workload from one data center to another is one of the holy grails of data centers but to accomplish this we need Layer 2 data center interconnects (DCI), with technologies like OTV, VPLS, EoVPLS, and others. There’s also a distance limitation, as the latency between two datacenters needs to be 10 milliseconds or less. And since light can only travel so far in 10 ms, there is a fairly limited distance that you can effectively vMotion (200 kilometers, or a bit over 120 miles). That is, unless you have a Stargate.


You do have a Stargate in your data center, right?

And that’s just getting a VM from one data center to another, which someone described to me once as a parlor trick. By itself, it serves no purpose to move a VM from one data center to another. You have to get its storage over as well (VMDK files if your lucky, raw LUNs if you’re not) and deal with the traffic tromboning problem from one data center to another.

The IP address is still coupled to the server (identity and location are coupled in normal operations, something LISP is meant to address), so traffic still comes to the server via the original data center, traverses the DCI, then the server responds through its default gateway, which is still likely the original data center. All that work to get a VM to a different data center, wasted.


All for one very simple reasons: A VM needs to keep its IP address when it moves. It’s IP statefullness, and there are various solutions that attempt to address the limitations of IP statefullness. Some DCI technologies like OTV will help keep default gateways to the local data center, so when a server responds it at least doesn’t trombone back through the original data center. LISP is (another) overlay protocol meant to decouple the location from the identity of a VM, helping with mobility. But as you add all these stopgap solutions on top of each other, it becomes more and more cumbersome (and expensive) to manage.

All of this because a VM doesn’t want to give its IP address up.

But that isn’t the reason why we need to let go of vMotion.

The real reason why it needs to go is that it’s holding us back.

Do you want to really scale your application? Do you want to have fail-over from one data center to another, especially over distances greater than 200 kilometers? Do you want to be be able to “follow the Sun” in terms of moving your workload? You can’t rely on vMotion. It’s not going to do it, even with all the band-aids meant to help it.

The sites that are doing this type of scaling are not relying on vMotion, they’re decoupling the application from the VM. It’s the metaphor of pets versus cattle (or as I like to refer to it, bridge crew versus redshirts). Pets is the old way, the traditional virtualization model. We care deeply what happens to a VM, so we put in all sorts of safety nets to keep that VM safe. vMotion, HA, DRS, even Fault Tolerance. With cattle (or redshirts), we don’t really care what happens to the VMs. The application is decoupled from the VM, and state is not solely stored on a single VM. The “shopping cart” problem, familiar to those who work with load balancers, isn’t an issue. So a simple load balancer is all that’s required, and can send traffic to another server without disrupting the user experience. Any VM can go away at any level (database, application, presentation/web layer) and the user experience will be undisturbed. We don’t shed a tear when a redshirt bites it, thus vMotion/HA/DRS are not needed.

If you write your applications and build your application stack as if vMotion didn’t exit, scaling and redundancy are geographic diversification get a lot easier. If your platform requires Layer 2 adjacency, you’re doing it wrong (and you’ll be severely limited in how you can scale).

And don’t take my word for it. Take a look at any of the huge web sites, Netflix, Twitter, Facebook: They all shard their workloads across the globe and across their infrastructure (or Amazons). Most of them don’t even use virtualization. Traditional servers sitting behind a load balancer with a active/standby pair of databases on the back-end isn’t going to cut it.

When you talk about sharding, make sure people know it’s spelled with a “D”.

If you write an application on Amazon’s AWS, you’re probably already doing this since there’s no vMotion in AWS. If an Amazon data center has a problem, as long as the application is architected correctly (again, done on the application itself), then I can still watch my episodes of Star Trek: Deep Space 9. It takes more work to do it this way, but it’s a far more effective way to scale/diversify your geography.

It’s much easier (and quicker) to write a web application for the traditional model of virtualization. And most sites first outing will probably be done in this way. But if you want to scale, it will be way easier (and more effective) to build and scale an application.

VMware’s vMotion (and Live Migration, and other similar technologies by other vendors) had their place, and they helped us move from the physical to the virtual. But now it’s holding us back, and it’s time for it to go.
